Advent of Code 2021 Day 24: Arithmetic Logic Unit

By Andreas Røssland

December 24, 2021

https://adventofcode.com/2021/day/24 https://github.com/roessland/advent-of-code

The task for today is to figure out the highest valid input for a program. This turned out to be more of a reverse engineering task than a programming task.

Dependency graph

By keeping track of which command changed a register during execution I can make a dependency graph of the entire program.

For example, the following program:

Takes a non-negative integer as input, converts it into binary, and stores the lowest (1’s) bit in z, the second-lowest (2’s) bit in y, the third-lowest (4’s) bit in x, and the fourth-lowest (8’s) bit in w:

inp w
add z w
mod z 2
div w 2
add y w
mod y 2
div w 2
add x w
mod x 2
div w 2
mod w 2

Has the following dependency graph:

Applying the same technique to the much larger input program, results in a huge graph too big to display here. It is obvious from the graph that there is some kind of structure: 14 modules that share only a single node with the next and previous modules. By cutting the program into modules at these “bottleneck” nodes, it can be decomposed into a pipeline of that is easier to understand. At these nodes the state is given only by z, and the other registers don’t matter. (Since they will be overridden using e.g. mul x 0 in the next module.) Each module takes only 2 inputs: The value of the z register after the previous module, and an input digit. None of them depend on the x, y and w registers.

I have cropped the program to show only the first module. Since it is the first module it does not depend on the z register (since it is initially 0).

This is a dependency graph (directed acyclic graph), and computation flows right to left. “add z y” on the left depends on everything to its right. When “add z y” has been performed, the registers contain the output of the module. The input arrow dependency from the previous module is missing in this image.

Modules

I will name these modules $f_{k} (i_{k}, z)$ , where $k$ is the module number $0, 1, \dots 13$ , $i_{k}$ is the input for module $k$ , and $z$ is the value of the $z$ register at the start of the module. The output of $f_{k}$ is the value of the $z$ register after the module has been executed. $z_{a f t e r} = f_{k} (i_{k}, z_{b e f o r e})$ The task is the find the largest input sequence which yields $z = 0$ after executing the program. Define $F_{k} (i)$ to be the value of the $z$ register after running the first $k$ modules with $i_{k}$ as input, and passing that into the next module. $F_{k}$ can be found given $F_{k - 1}$ and $f (k)$ , like this: $F_{k} (i) = f_{k} (i_{k}, F_{k - 1} (i))$

Or in “Haskell syntax” with partial application, currying and piping:

F_k(i) = f0 i0 0 | f1 i1 | f2 i2 | f3 i3 | f4 i4 | f5 i5 | f6 i6 | f7 i7 | f8 i8 | f9 i9 | f10 i10 | f11 i11 | f12 i12 | f13 i13

With memoization (which turned out to be useless and badly performing) you could write it like this in Go. I use the fact that each module is exactly 18 lines long to do the splitting.

allInstrs := ParseFile("input.txt")

fk := map[int]func(z int, d int) int{}
cache := map[Triplet]int{}
for i := 0; i < 14; i++ {
   fk[i] = (func(i_ int) func(z, in int) int {
      return func(z, in int) int {
         cached, ok := cache[Triplet{i_, z, in}]
         if ok {
            return cached
         }
         instrs := allInstrs[i_*18 : (i_+1)*18]
         ret := Compute(instrs, []int{in}, Reg{Z: z}).Z
         cache[Triplet{i_, z, in}] = ret
         return ret
      }
   })(i)
}

F := map[int]func([]int) int{}
F[0] = func(is []int) int {
   return fk[0](0, is[0])
}
for i := 1; i < 14; i++ {
   F[i] = func(i_ int) func([]int) int {
      return func(is []int) int {
         return fk[i_](F[i_-1](is), is[i_])
      }
   }(i)
}

// The entire input program is now F[13] and the final module is f[13].

First attempt at an algorithm

Define the set of valid inputs for $f_{14}$ as $0$ . ( $f_{13}$ is the final module, but when looping through module 13 we need to refer to the next module.)
For each module, starting at the final module
- Loop over all possible inputs $i$ and $z$ and store a set of $(i, z)$ where $f_{k} (i, z)$ is contained in the set of valid inputs for $f_{k + 1}$ .
Loop through the list of valid inputs $f_{0}$ and move back through the sets to build an input string. Pick the highest input.

This didn’t work, likely since $z$ becomes too big at some point. I had to limit the algorithm to a feasible set of z’s (-1e6 to 1e6), and even then I ended up with zero valid inputs for $f_{0}$ . I confirmed this by printing $z$ for random inputs, and found that $z$ can be in the range $10^{10}$ which is completely infeasible with this method, since the sets become too large to store in memory.

func FirstAlgo(f ModuleFunc, F CumulativeFunc) {
	validInputs := map[int]map[Pair]bool{}
	validInputs[14] = map[Pair]bool{Pair{1, 0}: true}

	Nz := 10000

	for k := 13; k >= 0; k-- {
		validInputs[k] = map[Pair]bool{}
		for dk := 1; dk <= 9; dk++ {
			for zk := -Nz; zk < Nz; zk++ {
				zNext := f[k](zk, dk)
				if validInputs[k+1][Pair{1, zNext}] ||
					validInputs[k+1][Pair{2, zNext}] ||
					validInputs[k+1][Pair{3, zNext}] ||
					validInputs[k+1][Pair{4, zNext}] ||
					validInputs[k+1][Pair{5, zNext}] ||
					validInputs[k+1][Pair{6, zNext}] ||
					validInputs[k+1][Pair{7, zNext}] ||
					validInputs[k+1][Pair{8, zNext}] ||
					validInputs[k+1][Pair{9, zNext}] {
					validInputs[k][Pair{dk, zk}] = true
				}
			}
		}
	}

	for pair := range validInputs[0] {
		fmt.Print(pair.B, " ")
	}
}

This code finds many valid inputs for $f_{0}$ but they all require $z \neq 0$ , which is contradictory since the first input must have $z = 0$ :

-8 -111 -1 -110 -60 -139 -61 -2 -32 -5 -114 -9 -6 -59 -5 -138 -2 -1 -62 -1 -3 -7 -5 -1 -113 -3 -86 -1 -2 -3 -1 -112 -6 -3 -34 -4 -6 -84 -3 -33 -5 -136 -6 -36 -87 -2 -85 -6 -35 -140 -88 -5 -2 -4 -137 -58 -4 -10 -5 -4 -4

I assume that by having an enormous range for $z$ I would eventually find the answer. Possibly before the heat death of the universe.

A glimpse of hope: If larger z’s are somehow truncated in each module (for example if the output only depends on z mod 26 and not z) the input space could be compressed, making a similar algorithm feasible.

Compressing the valid input space

If each module does in fact only depend on z mod 26 then $z$ is a valid input if z%26 is valid input, and the valid inputs map will have a maximum size of 9 (number of digits) times 26 (the cardinality of the ring of integers modulo 26, $Z / 26 Z$ , or simply $Z_{26}$ ) = 234 which is a trivial amount to store in memory, which should make my initial algorithm feasible.

To check this I analyzed the final module $f_{13}$ by hand to see if anything depends on $z$ instead of just $z$ . The x, y and z columns show the register values after the instruction in the first column has been executed. Note that the module doesn’t actually depend on x, y or w from the previous module. They are all overwritten with 0 before they are used.

op	x	y	z
$f_{12}$	`x=?`	`y=?`	`z=z12`
inp w	`x=?`	`y=?`	`z=z12`
mul x 0	`x=0`	`y=?`	`z=z12`
add x z	`x=z12`	`y=?`	`z=z12`
mod x 26	`x=z12%26`	`y=?`	`z=z12`
div z 26	`x=z12%26`	`y=?`	`z=z12/26`
add x -4	`x=z12%26-4`	`y=?`	`z=z12/26`
eql x w	`x=z12%26-4=in13`	`y=?`	`z=z12/26`
eql x 0	`x=z12%26-4!=in13`	`y=?`	`z=z12/26`
mul y 0	`x=z12%26-4!=in13`	`y=0`	`z=z12/26`
add y 25	`x=z12%26-4!=in13`	`y=25`	`z=z12/26`
mul y x	`x=z12%26-4!=in13`	`y=25*(z12%26-4!=in13)`	`z=z12/26`
add y 1	`x=z12%26-4!=in13`	`y=25*(z12%26-4!=in13)+1`	`z=z12/26`
mul z y	`x=z12%26-4!=in13`	`y=25*(z12%26-4!=in13)+1`	`z=z12/26(25(z12%26-4!=in13)+1)`
mul y 0	`x=z12%26-4!=in13`	`y=0`	`z=z12/26(25(z12%26-4!=in13)+1)`
add y w	`x=z12%26-4!=in13`	`y=in13`	`z=z12/26(25(z12%26-4!=in13)+1)`
add y 11	`x=z12%26-4!=in13`	`y=in13+11`	`z=z12/26(25(z12%26-4!=in13)+1)`
mul y x	`x=z12%26-4!=in13`	`y=(in13+11)*(z12%26-4!=in13)`	`z=z12/26(25(z12%26-4!=in13)+1)`
add z y	`x=z12%26-4!=in13`	`y=(in13+11)*(z12%26-4!=in13)`	`z=z12/26(25(z12%26-4!=in13)+1)+(in13+11)*(z12%26-4!=in13)`
output			`z=z12/26(25(z12%26-4!=in13)+1)+(in13+11)*(z12%26-4!=in13)`

Notice that the final output $z_{13}$ depends not only on $z mod 13$ but also $z / 26$ . $L A T E X$ notation to make it somewhat more readable: $z_{13} = ⌊ \frac{z_{12}}{26} ⌋ \cdot (25 ((z_{12} mod 26 - 4 \neq i_{13})) + 1) + (i_{13} + 11) \cdot (z_{12} mod 6 - 4 \neq i_{13})$ Unfortunately, it is not immediately obvious whether or not we can reduce the input space.

Analyzing $z_{13} = 0$

I need to find $i$ so that $z_{13} = 0$ . This can happen when either

The parts are both zero: $⌊ \frac{z_{12}}{26} ⌋ \cdot (25 ((z_{12} mod 26 - 4 \neq i_{13}) + 1) = 0$ and $(i_{13} + 11) \cdot (z_{12} mod 6 - 4 \neq i_{13}) = 0$
The parts negate each other: $⌊ \frac{z_{12}}{26} ⌋ \cdot (25 (z_{12} mod 26 - 4 \neq i_{13}) + 1) = - (i_{13} + 11) \cdot (z_{12} mod 26 - 4 \neq i_{13})$
- This can never happen since $(a \neq b) \geq 0 \forall a, b$ . So the left side is always $\geq 0$ , and the right side is always $\leq 0$ , so both must be 0 for this to be true.

Comparing the modules

Each module has subtly different constants. I wrote a small function to print all instructions sorted by their index in each module, instead of their global index:

func CompareModules(allInstrs []Instruction) {
   for k := -1; k < 14; k++ {
      fmt.Printf("|k=%d", k)
   }
   fmt.Println("|")
   for k := -1; k < 14; k++ {
      fmt.Printf("|----")
   }
   fmt.Println("|")

   for i := 0; i < 18; i++ {
      fmt.Printf("|%d|", i)
      for k := 0; k < 14; k++ {
         instr := allInstrs[k*18+i]
         fmt.Print(instr, "|")
      }
      fmt.Println()
   }
}

The input program looks very pretty as table.

	k=0	k=1	k=2	k=3	k=4	k=5	k=6	k=7	k=8	k=9	k=10	k=11	k=12	k=13
0	inp w	inp w	inp w	inp w	inp w	inp w	inp w	inp w	inp w	inp w	inp w	inp w	inp w	inp w
1	mul x 0	mul x 0	mul x 0	mul x 0	mul x 0	mul x 0	mul x 0	mul x 0	mul x 0	mul x 0	mul x 0	mul x 0	mul x 0	mul x 0
2	add x z	add x z	add x z	add x z	add x z	add x z	add x z	add x z	add x z	add x z	add x z	add x z	add x z	add x z
3	mod x 26	mod x 26	mod x 26	mod x 26	mod x 26	mod x 26	mod x 26	mod x 26	mod x 26	mod x 26	mod x 26	mod x 26	mod x 26	mod x 26
4 (a)	div z 1	div z 1	div z 1	div z 1	div z 26	div z 1	div z 1	div z 26	div z 26	div z 26	div z 1	div z 26	div z 26	div z 26
5 (b)	add x 14	add x 15	add x 12	add x 11	add x -5	add x 14	add x 15	add x -13	add x -16	add x -8	add x 15	add x -8	add x 0	add x -4
6	eql x w	eql x w	eql x w	eql x w	eql x w	eql x w	eql x w	eql x w	eql x w	eql x w	eql x w	eql x w	eql x w	eql x w
7	eql x 0	eql x 0	eql x 0	eql x 0	eql x 0	eql x 0	eql x 0	eql x 0	eql x 0	eql x 0	eql x 0	eql x 0	eql x 0	eql x 0
8	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0
9	add y 25	add y 25	add y 25	add y 25	add y 25	add y 25	add y 25	add y 25	add y 25	add y 25	add y 25	add y 25	add y 25	add y 25
10	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x
11	add y 1	add y 1	add y 1	add y 1	add y 1	add y 1	add y 1	add y 1	add y 1	add y 1	add y 1	add y 1	add y 1	add y 1
12	mul z y	mul z y	mul z y	mul z y	mul z y	mul z y	mul z y	mul z y	mul z y	mul z y	mul z y	mul z y	mul z y	mul z y
13	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0	mul y 0
14	add y w	add y w	add y w	add y w	add y w	add y w	add y w	add y w	add y w	add y w	add y w	add y w	add y w	add y w
15 (c)	add y 12	add y 7	add y 1	add y 2	add y 4	add y 15	add y 11	add y 5	add y 3	add y 9	add y 2	add y 3	add y 3	add y 11
16	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x	mul y x
17	add z y	add z y	add z y	add z y	add z y	add z y	add z y	add z y	add z y	add z y	add z y	add z y	add z y	add z y

From this table it is clear each module only differ by 3 constants, in instructions 4, 5 and 15. Let’s call these constants $a$ , $b$ and $c$ .

$a$ is either 1 or 26.
$b$ varies between -16 and 15.
$c$ varies between 1 and 15.

By analyzing $f_{13}$ again, but using these variables instead, we more general expressions that represents the modules:

$\begin{aligned} z_{0} & = (i_{0} + c_{0}) \cdot (b_{0} \neq i_{k}) \\ z_{1} & = ⌊ \frac{z_{0}}{a_{1}} ⌋ \cdot (25 (z_{0} mod 26 + b_{1} \neq i_{1})) + 1) + (i_{1} + c_{1}) \cdot (z_{0} mod 26 + b_{1} \neq i_{1}) \\ ⋮ \\ z_{k} & = ⌊ \frac{z_{k - 1}}{a_{k}} ⌋ \cdot (25 (z_{k - 1} mod 26 + b_{k} \neq i_{k})) + 1) + (i_{k} + c_{k}) \cdot (z_{k - 1} mod 26 + b_{k} \neq i_{k}) \end{aligned}$

At this point I can compute $F_{13}$ much faster than simulating the ALU. The ALU simulator runs the program in around 1166 nanoseconds, while this function runs in only 50 nanoseconds, a speedup of ~23 times. But looping over the entire input will still take $10^{14} \cdot 50, ns$ = 57 days… My bruteforce function fails to find a single valid input in reasonable time.

func F13(a, b, c, i []int) int {
	var z int
	for k := 0; k < 14; k++ {
		z = z/a[k]*(25*(asInt(z%26+b[k] != i[k]))+1) + (i[k]+c[k])*asInt(z%26+b[k] != i[k])
	}
	return z
}

Graph traversal

At this point it was midnight, and I had been working on this problem for several hours, and I was almost ready to give up and look up the solution. For the hell of it, I tried a simple graph search. It worked 🤦‍♂️.

I started with Dijkstra and used $\sum_{k} z_{k}$ as the priority for each node, which very quickly finds some solution, but not the solution with the highest input. By modifying the logic used for backtracking (finding the path taken after the target node is reached) to prefer low digits or high digits I found the answer to both part 1 and 2.

I realized that all paths must be followed since we need both the highest and the lowest input, so the algorithm cannot simply abort when the target has been found; it must run until all paths to the target has been found. Thus Dijkstra doesn’t really make sense, and I switched from a priority queue to a set.

It is an exhaustive walk through the possible graph states in a random order. The state is represented as a tuple of $k$ and $z_{k}$ , where $k$ is the module number and $z_{k}$ is the value of the $z$ register before the module runs. The initial state is $(k = 0, z = 0)$ and the target state is $(k = 14, z = 0)$ (since we want the output of $f_{13}$ to be 0).

type State struct {
	K, Z int
}

func ComputePruningLimits() []int {
   limits := make([]int, len(a)+1)
   limits[13] = 26
   for k := 12; k >= 0; k-- {
      if a[k] == 26 {
         limits[k] = limits[k+1]*26 + 26
      } else {
         limits[k] = limits[k+1] + 26
      }
   }
   return limits
}

func GraphSearch(max bool) int {
   limits := ComputePruningLimits()
   visited := map[State]bool{}
   S := map[State]struct{}{}
   S[State{0, 0}] = struct{}{}
   prev := map[State]State{}
   digit := map[State]int{}
   var results []int

   for len(S) > 0 {
      var nodeCurr State
      for s := range S {
         nodeCurr = s
         break
      }
      delete(S, nodeCurr)
      visited[nodeCurr] = true

      k := nodeCurr.K
      z := nodeCurr.Z

      // Pruning branches with too high / unrecoverable z value.
      if z > limits[k] {
         continue
      }

      if k == 14 {
         if z == 0 {
            digits := []int{}
            for nodeCurr != (State{0, 0}) {
               digits = append(digits, digit[nodeCurr])
               nodeCurr = prev[nodeCurr]
            }
            sliceutil.ReverseInt(digits)
            results = append(results, mathutil.FromDigitsInt(digits, 10))
         }
         continue
      }
      for i := 1; i <= 9; i++ {
         zNext := f(z, i, k)
         nodeNext := State{k + 1, zNext}
         switchedDigit := false
         if digit[nodeNext] == 0 {
            prev[nodeNext] = nodeCurr
            digit[nodeNext] = i
            switchedDigit = true
         } else if max && i >= digit[nodeNext] {
            prev[nodeNext] = nodeCurr
            digit[nodeNext] = i
            switchedDigit = true
         } else if !max && i <= digit[nodeNext] {
            prev[nodeNext] = nodeCurr
            digit[nodeNext] = i
            switchedDigit = true
         }
         if switchedDigit { //
            S[nodeNext] = struct{}{}
         }
      }
   }
   sort.Ints(results)
   if max {
      return results[len(results)-1]
   } else {
      return results[0]
   }
}

This runs in about 5 seconds, and finds the answer to both part 1 and part 2. Run it with max=true for part 1 and max=false for part 2. Without branch pruning it takes about a minute.

Appendix 1: All the code

package main

import (
   "bufio"
   "fmt"   "github.com/roessland/gopkg/mathutil"   "github.com/roessland/gopkg/sliceutil"   "io"   "log"   "math/rand"   "os"   "sort"   "strconv"   "strings"   "time")

var a, b, c []int

func init() {
   allInstrs := ParseFile("input.txt")
   a, b, c = ExtractABC(allInstrs)
}

type InstructionType int

const (
   Inp InstructionType = iota
   AddC
   AddP   MulC   MulP   DivC   DivP   ModC   ModP   EqlC   EqlP)

type Reg struct {
   W, X, Y, Z int
}

func (r *Reg) Set(name int, val int) {
   switch name {
   case 'w':
      r.W = val
   case 'x':
      r.X = val
   case 'y':
      r.Y = val
   case 'z':
      r.Z = val
   default:
      panic("no such register")
   }
}

func (r *Reg) Get(name int) int {
   switch name {
   case 'w':
      return r.W
   case 'x':
      return r.X
   case 'y':
      return r.Y
   case 'z':
      return r.Z
   default:
      panic("no such register")
   }
}

func Compute(instrs []Instruction, inps []int, reg Reg) Reg {
   inpCount := 0
   for _, instr := range instrs {
      switch instr.Type {
      case Inp:
         reg.Set(instr.A, inps[inpCount])
         inpCount++
      case AddC:
         reg.Set(instr.A, reg.Get(instr.A)+instr.B)
      case AddP:
         reg.Set(instr.A, reg.Get(instr.A)+reg.Get(instr.B))
      case MulC:
         reg.Set(instr.A, reg.Get(instr.A)*instr.B)
      case MulP:
         reg.Set(instr.A, reg.Get(instr.A)*reg.Get(instr.B))
      case DivC:
         reg.Set(instr.A, reg.Get(instr.A)/instr.B)
      case DivP:
         reg.Set(instr.A, reg.Get(instr.A)/reg.Get(instr.B))
      case ModC:
         reg.Set(instr.A, reg.Get(instr.A)%instr.B)
      case ModP:
         reg.Set(instr.A, reg.Get(instr.A)%reg.Get(instr.B))
      case EqlC:
         if reg.Get(instr.A) == instr.B {
            reg.Set(instr.A, 1)
         } else {
            reg.Set(instr.A, 0)
         }
      case EqlP:
         if reg.Get(instr.A) == reg.Get(instr.B) {
            reg.Set(instr.A, 1)
         } else {
            reg.Set(instr.A, 0)
         }
      }
   }
   return reg
}

func Compute2(instrs []Instruction, inps []int) Reg {
   reg := Reg{}

   inpCount := 0
   lastModified := Reg{}
   for i, instr := range instrs {
      fmt.Printf("%d[\"%s\"]\n", i, instr.Text)
      deps := []int{}
      switch instr.Type {
      case Inp:
         reg.Set(instr.A, inps[inpCount])
         deps = append(deps, 1000+inpCount)
         lastModified.Set(instr.A, i)
         inpCount++
      case AddC:
         reg.Set(instr.A, reg.Get(instr.A)+instr.B)
         deps = append(deps, lastModified.Get(instr.A))
         lastModified.Set(instr.A, i)
      case AddP:
         reg.Set(instr.A, reg.Get(instr.A)+reg.Get(instr.B))
         deps = append(deps, lastModified.Get(instr.A))
         deps = append(deps, lastModified.Get(instr.B))
         lastModified.Set(instr.A, i)
      case MulC:
         reg.Set(instr.A, reg.Get(instr.A)*instr.B)
         if instr.B != 0 {
            deps = append(deps, lastModified.Get(instr.A))
         }
         lastModified.Set(instr.A, i)
      case MulP:
         reg.Set(instr.A, reg.Get(instr.A)*reg.Get(instr.B))
         deps = append(deps, lastModified.Get(instr.A))
         deps = append(deps, lastModified.Get(instr.B))
         lastModified.Set(instr.A, i)
      case DivC:
         reg.Set(instr.A, reg.Get(instr.A)/instr.B)
         deps = append(deps, lastModified.Get(instr.A))
         lastModified.Set(instr.A, i)
      case DivP:
         reg.Set(instr.A, reg.Get(instr.A)/reg.Get(instr.B))
         deps = append(deps, lastModified.Get(instr.A))
         deps = append(deps, lastModified.Get(instr.B))
         lastModified.Set(instr.A, i)
      case ModC:
         reg.Set(instr.A, reg.Get(instr.A)%instr.B)
         deps = append(deps, lastModified.Get(instr.A))
         lastModified.Set(instr.A, i)
      case ModP:
         reg.Set(instr.A, reg.Get(instr.A)%reg.Get(instr.B))
         deps = append(deps, lastModified.Get(instr.A))
         deps = append(deps, lastModified.Get(instr.B))
         lastModified.Set(instr.A, i)
      case EqlC:
         if reg.Get(instr.A) == instr.B {
            reg.Set(instr.A, 1)
         } else {
            reg.Set(instr.A, 0)
         }
         deps = append(deps, lastModified.Get(instr.A))
         lastModified.Set(instr.A, i)
      case EqlP:
         if reg.Get(instr.A) == reg.Get(instr.B) {
            reg.Set(instr.A, 1)
         } else {
            reg.Set(instr.A, 0)
         }
         deps = append(deps, lastModified.Get(instr.A))
         deps = append(deps, lastModified.Get(instr.B))
         lastModified.Set(instr.A, i)
      default:
         panic("bruh")
      }

      if len(deps) == 1 {
         fmt.Printf("%d --> %d\n", i, deps[0])
      }
      if len(deps) == 2 {
         fmt.Printf("%d --> %d & %d\n", i, deps[0], deps[1])
      }

   }
   fmt.Printf("z --> %d\n", lastModified.Z)

   os.Exit(0)
   return reg
}

type Instruction struct {
   Type InstructionType
   A    int
   B    int
   Text string
}

func (i Instruction) String() string {
   return i.Text
}

func ParseFile(filename string) []Instruction {
   f, err := os.Open(filename)
   if err != nil {
      log.Fatal(err)
   }
   return ParseInput(f)
}

func ParseString(s string) []Instruction {
   r := strings.NewReader(s)
   return ParseInput(r)
}

func ParseInput(r io.Reader) []Instruction {
   var instructions []Instruction
   scanner := bufio.NewScanner(r)
   for scanner.Scan() {
      line := strings.TrimSpace(scanner.Text())
      if len(line) == 0 {
         continue
      }
      codeComment := strings.SplitN(line, "//", 2)
      parts := strings.Split(strings.TrimSpace(codeComment[0]), " ")
      name := parts[0]
      if len(parts) == 1 {
         continue
      }
      a := parts[1]
      b := ""
      var instr Instruction
      instr.Text = line
      var isPtr bool
      var bInt int
      if len(parts) > 2 {
         b = parts[2]
         if len(b) == 0 {
            panic(fmt.Sprintf("wtf: %v", parts))
         }
         isPtr = 'a' <= b[0] && b[0] <= 'z'
         bInt, _ = strconv.Atoi(b)
      }

      type Op struct {
         Name  string
         IsPtr bool
      }
      op := Op{name, isPtr}
      switch op {
      case Op{"inp", false}:
         instr.Type = Inp
         instr.A = int(a[0])
      case Op{"add", false}:
         instr.Type = AddC
         instr.A = int(a[0])
         instr.B = bInt
      case Op{"add", true}:
         instr.Type = AddP
         instr.A = int(a[0])
         instr.B = int(b[0])
      case Op{"mul", false}:
         instr.Type = MulC
         instr.A = int(a[0])
         instr.B = bInt
      case Op{"mul", true}:
         instr.Type = MulP
         instr.A = int(a[0])
         instr.B = int(b[0])
      case Op{"div", false}:
         instr.Type = DivC
         instr.A = int(a[0])
         instr.B = bInt
      case Op{"div", true}:
         instr.Type = DivP
         instr.A = int(a[0])
         instr.B = int(b[0])
      case Op{"mod", false}:
         instr.Type = ModC
         instr.A = int(a[0])
         instr.B = bInt
      case Op{"mod", true}:
         instr.Type = ModP
         instr.A = int(a[0])
         instr.B = int(b[0])
      case Op{"eql", false}:
         instr.Type = EqlC
         instr.A = int(a[0])
         instr.B = bInt
      case Op{"eql", true}:
         instr.Type = EqlP
         instr.A = int(a[0])
         instr.B = int(b[0])
      }
      instructions = append(instructions, instr)
   }
   return instructions
}

type Pair struct {
   A, B int
}

type Triplet struct {
   A, B, C int
}

type ModuleFunc map[int]func(z int, d int) int
type CumulativeFunc map[int]func([]int) int

func CompareModules(allInstrs []Instruction) {
   for k := -1; k < 14; k++ {
      fmt.Printf("|k=%d", k)
   }
   fmt.Println("|")
   for k := -1; k < 14; k++ {
      fmt.Printf("|----")
   }
   fmt.Println("|")

   for i := 0; i < 18; i++ {
      fmt.Printf("|%d|", i)
      for k := 0; k < 14; k++ {
         instr := allInstrs[k*18+i]
         fmt.Print(instr, "|")
      }
      fmt.Println()
   }
}

func ExtractABC(allInstrs []Instruction) (as, bs, cs []int) {
   for k := 0; k < 14; k++ {
      instr := allInstrs[k*18+4]
      as = append(as, instr.B)
   }

   for k := 0; k < 14; k++ {
      instr := allInstrs[k*18+5]
      bs = append(bs, instr.B)
   }

   for k := 0; k < 14; k++ {
      instr := allInstrs[k*18+15]
      cs = append(cs, instr.B)
   }

   return as, bs, cs
}

func GetModulesWithMemoization(allInstrs []Instruction) (fk ModuleFunc, Fk CumulativeFunc) {
   fk = make(ModuleFunc)
   cache := map[Triplet]int{}
   for i := 0; i < 14; i++ {
      fk[i] = (func(i_ int) func(z, in int) int {
         return func(z, in int) int {
            cached, ok := cache[Triplet{i_, z, in}]
            if ok {
               return cached
            }
            instrs := allInstrs[i_*18 : (i_+1)*18]
            ret := Compute(instrs, []int{in}, Reg{Z: z}).Z
            cache[Triplet{i_, z, in}] = ret
            return ret
         }
      })(i)
   }

   F := map[int]func([]int) int{}
   F[0] = func(is []int) int {
      return fk[0](0, is[0])
   }
   for i := 1; i < 14; i++ {
      F[i] = func(i_ int) func([]int) int {
         return func(is []int) int {
            return fk[i_](F[i_-1](is), is[i_])
         }
      }(i)
   }

   return fk, F
}

func RandomizeInput(inps []int) {
   for i := 0; i < len(inps); i++ {
      inps[i] = 1 + rand.Intn(9)
   }
}

func PartialRandomizeInput(inps []int) {
   inps[rand.Intn(len(inps))] = 1 + rand.Intn(9)
}

func FirstAlgo() {
   validInputs := map[int]map[int]bool{}
   validInputs[14] = map[int]bool{0: true}

   zMax := 10760000
   for k := 13; k >= 6; k-- {
      validInputs[k] = map[int]bool{}
      for zk := 0; zk < zMax; zk++ {
         for dk := 1; dk <= 9; dk++ {
            zNext := f(zk, dk, k)
            if validInputs[k+1][zNext] {
               validInputs[k][zk] = true
            }
         }
      }
   }

   for k := 0; k < 14; k++ {
      if zk, ok := validInputs[k]; ok {
         fmt.Println(k, len(zk), " ")
      }
   }
}

func asInt(b bool) int {
   if b {
      return 1
   }
   return 0
}

func f(z, i, k int) int {
   a := a[k]
   b := b[k]
   c := c[k]
   return z/a*(25*(asInt(z%26+b != i))+1) + (i+c)*asInt(z%26+b != i)
}

func Codegen(a, b, c, i []int) (z int) {
   for k := 0; k < 14; k++ {
      z = f(z, i[k], k)
   }
   return z
}

func computeZ1() {
   // [{1 13} {2 346} {3 9005} {4 234136} {5 9005} {6 234147} {7 6087836} {8 234147} {9 9005} {10 346} {11 9005} {12 346} {13 13} {14 0}] [1 1 8 4 1 2 3 1 1 1 7 1 8 9]
   //11841231117189   // 1 1 8   for d := 1; d <= 9; d++ {
      fmt.Println(d, f(346, d, 13))
   }
}

func F13(i []int) (z int) {
   asInt := func(b bool) int {
      if b {
         return 1
      }
      return 0
   }

   z = z/1*(25*(asInt(z%26+14 != i[0]))+1) + (i[0]+12)*asInt(z%26+14 != i[0])
   z = z/1*(25*(asInt(z%26+15 != i[1]))+1) + (i[1]+7)*asInt(z%26+15 != i[1])
   z = z/1*(25*(asInt(z%26+12 != i[2]))+1) + (i[2]+1)*asInt(z%26+12 != i[2])
   z = z/1*(25*(asInt(z%26+11 != i[3]))+1) + (i[3]+2)*asInt(z%26+11 != i[3])
   z = z/26*(25*(asInt(z%26+-5 != i[4]))+1) + (i[4]+4)*asInt(z%26+-5 != i[4])
   z = z/1*(25*(asInt(z%26+14 != i[5]))+1) + (i[5]+15)*asInt(z%26+14 != i[5])
   z = z/1*(25*(asInt(z%26+15 != i[6]))+1) + (i[6]+11)*asInt(z%26+15 != i[6])
   z = z/26*(25*(asInt(z%26+-13 != i[7]))+1) + (i[7]+5)*asInt(z%26+-13 != i[7])
   z = z/26*(25*(asInt(z%26+-16 != i[8]))+1) + (i[8]+3)*asInt(z%26+-16 != i[8])
   z = z/26*(25*(asInt(z%26+-8 != i[9]))+1) + (i[9]+9)*asInt(z%26+-8 != i[9])
   z = z/1*(25*(asInt(z%26+15 != i[10]))+1) + (i[10]+2)*asInt(z%26+15 != i[10])
   z = z/26*(25*(asInt(z%26+-8 != i[11]))+1) + (i[11]+3)*asInt(z%26+-8 != i[11])
   z = z/26*(25*(asInt(z%26+0 != i[12]))+1) + (i[12]+3)*asInt(z%26+0 != i[12])
   z = z/26*(25*(asInt(z%26+-4 != i[13]))+1) + (i[13]+11)*asInt(z%26+-4 != i[13])
   return z
}

func Bruteforce() {
   //for nthread := 0; nthread < 1; nthread++ {
   // go func() {   inps := []int{1, 1, 9, 9, 6, 2, 3, 1, 1, 1, 7, 1, 8, 9}
   //inps := []int{1, 1, 8, 4, 5, 6, 7, 8, 9, 1, 2, 3, 4, 5}
   for i := 0; ; i++ {
      PartialRandomizeInput(inps[5:])
      z := F13(inps)
      if z == 0 {
         fmt.Println("z", z, "inps", inps)

         inps64 := make([]int64, len(inps))
         for d := 0; d < len(inps64); d++ {
            inps64[d] = int64(inps[d])
         }
         input10 := mathutil.FromDigits(inps64[0:], 10)
         input26 := mathutil.ToDigitsInt(input10, 26)
         fmt.Println("base 26", input26)
      }

   }
   // }()
   //}   //time.Sleep(1000 * time.Second)}

type State struct {
   K, Z int
}

func ComputePruningLimits() []int {
   limits := make([]int, len(a)+1)
   limits[13] = 26
   for k := 12; k >= 0; k-- {
      if a[k] == 26 {
         limits[k] = limits[k+1]*26 + 26
      } else {
         limits[k] = limits[k+1] + 26
      }
   }
   return limits
}

func GraphSearch(max bool) int {
   limits := ComputePruningLimits()
   visited := map[State]bool{}
   S := map[State]struct{}{}
   S[State{0, 0}] = struct{}{}
   prev := map[State]State{}
   digit := map[State]int{}
   var results []int

   for len(S) > 0 {
      var nodeCurr State
      for s := range S {
         nodeCurr = s
         break
      }
      delete(S, nodeCurr)
      visited[nodeCurr] = true

      k := nodeCurr.K
      z := nodeCurr.Z

      // Pruning branches with too high / unrecoverable z value.
      if z > limits[k] {
         continue
      }

      if k == 14 {
         if z == 0 {
            digits := []int{}
            for nodeCurr != (State{0, 0}) {
               digits = append(digits, digit[nodeCurr])
               nodeCurr = prev[nodeCurr]
            }
            sliceutil.ReverseInt(digits)
            results = append(results, mathutil.FromDigitsInt(digits, 10))
         }
         continue
      }
      for i := 1; i <= 9; i++ {
         zNext := f(z, i, k)
         nodeNext := State{k + 1, zNext}
         switchedDigit := false
         if digit[nodeNext] == 0 {
            prev[nodeNext] = nodeCurr
            digit[nodeNext] = i
            switchedDigit = true
         } else if max && i >= digit[nodeNext] {
            prev[nodeNext] = nodeCurr
            digit[nodeNext] = i
            switchedDigit = true
         } else if !max && i <= digit[nodeNext] {
            prev[nodeNext] = nodeCurr
            digit[nodeNext] = i
            switchedDigit = true
         }
         if switchedDigit { //
            S[nodeNext] = struct{}{}
         }
      }
   }
   sort.Ints(results)
   if max {
      return results[len(results)-1]
   } else {
      return results[0]
   }
}

func main() {
   var t0 time.Time

   t0 = time.Now()
   fmt.Print("Part 1: ")
   a := GraphSearch(true)
   fmt.Println(a == 12996997829399, time.Since(t0))

   t0 = time.Now()
   fmt.Print("Part 2: ")
   b := GraphSearch(false)
   fmt.Println(b == 11841231117189, time.Since(t0))
}

// 12996997829399 part 1
// 11841231117189 part 2

Appendix 2: Tests

package main

import (
	"embed"
	"fmt"
	"github.com/stretchr/testify/assert"
	"github.com/stretchr/testify/require"
	"strings"
	"testing"
)

import _ "embed"

//go:embed input.txt
var fs embed.FS

func TestComputeNegate(t *testing.T) {
	instrs := []Instruction{
		{Type: Inp, A: 'x'},
		{Type: MulC, A: 'x', B: -1},
	}
	tcs := []struct {
		Name  string
		X     int
		Input []int
	}{
		{"-1 is -1", -1, []int{1}},
		{"-5 is -5", -5, []int{5}},
	}
	for _, tc := range tcs {
		t.Run(tc.Name, func(t *testing.T) {
			reg := Compute(instrs, tc.Input, Reg{})
			require.EqualValues(t, tc.X, reg.X)
		})
	}
}

func TestComputeIsTriple(t *testing.T) {
	instrs := []Instruction{
		{Type: Inp, A: 'z'},
		{Type: Inp, A: 'x'},
		{Type: MulC, A: 'z', B: 3},
		{Type: EqlP, A: 'z', B: 'x'},
	}
	tcs := []struct {
		Name   string
		Input  []int
		Expect int
	}{
		{
			"3*0 is 9",
			[]int{0, 0},
			1,
		},
		{
			"3*1 is 3",
			[]int{1, 3},
			1,
		},
		{
			"3*2 is not 5",
			[]int{2, 5},
			0,
		},
	}
	for _, tc := range tcs {
		t.Run(tc.Name, func(t *testing.T) {
			reg := Compute(instrs, tc.Input, Reg{})
			assert.Equal(t, tc.Expect, reg.Z)
		})
	}
}

func TestComputeBinary(t *testing.T) {
	instrs := []Instruction{
		{Type: Inp, A: 'w'},
		{Type: AddP, A: 'z', B: 'w'},
		{Type: ModC, A: 'z', B: 2},
		{Type: DivC, A: 'w', B: 2},
		{Type: AddP, A: 'y', B: 'w'},
		{Type: ModC, A: 'y', B: 2},
		{Type: DivC, A: 'w', B: 2},
		{Type: AddP, A: 'x', B: 'w'},
		{Type: ModC, A: 'x', B: 2},
		{Type: DivC, A: 'w', B: 2},
		{Type: ModC, A: 'w', B: 2},
	}
	tcs := []struct {
		Name   string
		Input  []int
		Expect string
	}{
		{
			"1 is 0b001",
			[]int{1},
			"0001",
		},
		{
			"2 is 0b010",
			[]int{2},
			"0010",
		},
		{
			"15 is 0b1111",
			[]int{15},
			"1111",
		},
	}
	for _, tc := range tcs {
		t.Run(tc.Name, func(t *testing.T) {
			reg := Compute(instrs, tc.Input, Reg{})
			w, x, y, z := reg.W, reg.X, reg.Y, reg.Z
			got := fmt.Sprintf("%d%d%d%d", w, x, y, z)
			assert.Equal(t, tc.Expect, got)
		})
	}
}

func TestComputeInpOut(t *testing.T) {
	instrs := []Instruction{
		{Type: Inp, A: 'w'},
		{Type: MulC, A: 'w', B: 2},
		{Type: Inp, A: 'x'},
		{Type: MulC, A: 'x', B: 3},
		{Type: Inp, A: 'y'},
		{Type: MulC, A: 'y', B: 4},
		{Type: Inp, A: 'z'},
		{Type: MulC, A: 'z', B: 5},
	}
	reg := Compute(instrs, []int{1, 2, 3, 4}, Reg{})
	require.EqualValues(t, Reg{1 * 2, 2 * 3, 3 * 4, 4 * 5}, reg)
}

func TestComputePtrs(t *testing.T) {
	// Inp 2
	//	AddP 2 + 3 = 5
	//	MulP (2+3)*4 = 20
	//	DivP (2+3)*4 / 2 = 10
	//	ModP (2+3)*4 / 2 % 3 = 1
	// Inp 1
	//	EqlP
	instrs := []Instruction{
		{Type: Inp, A: 'w'}, // w=2
		{Type: Inp, A: 'x'}, // x=3

		{Type: AddP, A: 'w', B: 'x'}, // w=5

		{Type: Inp, A: 'x'},          // x=4
		{Type: MulP, A: 'w', B: 'x'}, // w=20
		{Type: AddP, A: 'z', B: 'w'}, // z=20

		{Type: Inp, A: 'x'},          // x=2
		{Type: DivP, A: 'w', B: 'x'}, // w=10
		{Type: AddP, A: 'y', B: 'w'}, // y=10

		{Type: Inp, A: 'x'},          // x=3
		{Type: ModP, A: 'w', B: 'x'}, // w=1

		{Type: Inp, A: 'x'},          // x=1
		{Type: EqlP, A: 'x', B: 'w'}, // x=1
	}
	reg := Compute(instrs, []int{2, 3, 4, 2, 3, 1}, Reg{})
	require.EqualValues(t, Reg{1, 1, 10, 20}, reg)
}

func TestTrimSpaceTrimsTabs(t *testing.T) {
	input := "\tbanana"
	require.EqualValues(t, "banana", strings.TrimSpace(input))
}

func TestComputeParseString(t *testing.T) {
	input := `
		inp w // get input // yo
		inp x
		add w x
		inp x
		mul w x
		add z w
		inp x
		div w x
		add y w
		inp x
		mod w x
		inp x
		eql x w`
	actualInstrs := ParseString(input)
	expectedInstrs := []Instruction{
		{Type: Inp, A: 'w', Text: "inp w // get input // yo"},
		{Type: Inp, A: 'x', Text: "inp x"},
		{Type: AddP, A: 'w', B: 'x', Text: "add w x"},
		{Type: Inp, A: 'x', Text: "inp x"},
		{Type: MulP, A: 'w', B: 'x', Text: "mul w x"},
		{Type: AddP, A: 'z', B: 'w', Text: "add z w"},
		{Type: Inp, A: 'x', Text: "inp x"},
		{Type: DivP, A: 'w', B: 'x', Text: "div w x"},
		{Type: AddP, A: 'y', B: 'w', Text: "add y w"},
		{Type: Inp, A: 'x', Text: "inp x"},
		{Type: ModP, A: 'w', B: 'x', Text: "mod w x"},
		{Type: Inp, A: 'x', Text: "inp x"},
		{Type: EqlP, A: 'x', B: 'w', Text: "eql x w"},
	}
	require.EqualValues(t, expectedInstrs, actualInstrs)
}

func BenchmarkComputeInput(b *testing.B) {
	f, err := fs.Open("input.txt")
	if err != nil {
		b.Fatal(err)
	}
	instrs := ParseInput(f)
	inps := []int{1, 2, 3, 4, 5, 6, 7, 8, 9, 1, 2, 3, 4, 5}

	for j := 0; j < b.N; j++ {
		if j%1000 == 0 {
			RandomizeInput(inps)
		}
		Compute(instrs, inps, Reg{})
	}
}

func BenchmarkGeneratedCode(b *testing.B) {
	inps := []int{1, 2, 3, 4, 5, 6, 7, 8, 9, 1, 2, 3, 4, 5}

	for j := 0; j < b.N; j++ {
		if j%1000 == 0 {
			RandomizeInput(inps)
		}
		F13(inps)
	}
}

func BenchmarkCodegen(B *testing.B) {
	f, err := fs.Open("input.txt")
	if err != nil {
		B.Fatal(err)
	}
	instrs := ParseInput(f)
	a, b, c := ExtractABC(instrs)

	inps := []int{1, 2, 3, 4, 5, 6, 7, 8, 9, 1, 2, 3, 4, 5}
	for j := 0; j < B.N; j++ {
		if j%1000 == 0 {
			RandomizeInput(inps)
		}
		Codegen(a, b, c, inps)
	}
}

func BenchmarkModuleMemoization(b *testing.B) {
	f, err := fs.Open("input.txt")
	if err != nil {
		b.Fatal(err)
	}
	instrs := ParseInput(f)
	_, F := GetModulesWithMemoization(instrs)

	inps := []int{1, 2, 3, 4, 5, 6, 7, 8, 9, 1, 2, 3, 4, 5}
	for j := 0; j < b.N; j++ {
		if j%100 == 0 {
			RandomizeInput(inps)
		}
		F[13](inps)
	}
}

func TestGetModulesWithMemoization(t *testing.T) {
	f, err := fs.Open("input.txt")
	if err != nil {
		t.Fatal(err)
	}
	instrs := ParseInput(f)

	_, F := GetModulesWithMemoization(instrs)

	inps := []int{1, 2, 3, 4, 5, 6, 7, 8, 9, 1, 2, 3, 4, 5}
	require.Equal(t, Compute(instrs, inps, Reg{}).Z, F[13](inps))
}

func TestCodegen(t *testing.T) {
	f, err := fs.Open("input.txt")
	if err != nil {
		t.Fatal(err)
	}
	instrs := ParseInput(f)
	a, b, c := ExtractABC(instrs)

	inps := []int{1, 2, 3, 4, 5, 6, 7, 8, 9, 1, 2, 3, 4, 5}
	require.Equal(t, Compute(instrs, inps, Reg{}).Z, Codegen(a, b, c, inps))
}

func TestF13(t *testing.T) {
	f, err := fs.Open("input.txt")
	if err != nil {
		t.Fatal(err)
	}
	instrs := ParseInput(f)

	inps := []int{1, 2, 3, 4, 5, 6, 7, 8, 9, 1, 2, 3, 4, 5}
	for i := 0; i < 100; i++ {
		RandomizeInput(inps)
		require.Equal(t, Compute(instrs, inps, Reg{}).Z, F13(inps))
	}
}

func BenchmarkRandomizeInput(b *testing.B) {
	inps := []int{1, 2, 3, 4, 5, 6, 7, 8, 9, 1, 2, 3, 4, 5}
	for j := 0; j < b.N; j++ {
		RandomizeInput(inps)
	}
}

func BenchmarkPartialRandomizeInput(b *testing.B) {
	inps := []int{1, 2, 3, 4, 5, 6, 7, 8, 9, 1, 2, 3, 4, 5}
	for j := 0; j < b.N; j++ {
		PartialRandomizeInput(inps)
	}
}
